ion-item

Contents

Items are elements that can contain text, icons, avatars, images, inputs, and any other native or custom elements. Generally they are placed in a list with other items. Items can be swiped, deleted, reordered, edited, and more.

Detail Arrows

By default, clickable items will display a right arrow icon on ios mode. To hide the right arrow icon on clickable elements, set the detail property to false. To show the right arrow icon on an item that doesn't display it naturally, add the detail attribute to the item.

Item Placement

Item uses named slots in order to position content. This logic makes it possible to write a complex item with simple, understandable markup without having to worry about styling and positioning the elements.

The below chart details the item slots and where it will place the element inside of the item:

Slot Description
start Placed to the left of all other content in LTR, and to the right in RTL.
end Placed to the right of all other content in LTR, and to the left in RTL.
none Placed inside of the input wrapper.

Text Alignment

Items left align text and add an ellipsis when the text is wider than the item. See the Utility Attributes Documentation for attributes that can be added to <ion-item> to transform the text.

Input Highlight

Highlight Height

Items containing an input will highlight the input with a different color border when focused, valid, or invalid. By default, md items have a highlight with a height set to 2px and ios has no highlight (technically the height is set to 0). The height can be changed using the --highlight-height CSS property. To turn off the highlight, set this variable to 0. For more information on setting CSS properties, see the theming documentation.

Highlight Color

The highlight color changes based on the item state, but all of the states use Ionic colors by default. When focused, the input highlight will use the primary color. If the input is valid it will use the success color, and invalid inputs will use the danger color. See the CSS Custom Properties section below for the highlight color variables.

Usage

angular javascript

Basic Usage

<!-- Default Item -->
<ion-item>
  <ion-label>
    Item
  </ion-label>
</ion-item>

<!-- Item as a Button -->
<ion-item (click)="buttonClick()">
  <ion-label>
    Button Item
  </ion-label>
</ion-item>

<!-- Item as an Anchor -->
<ion-item href="https://www.ionicframework.com">
  <ion-label>
    Anchor Item
  </ion-label>
</ion-item>

<ion-item color="secondary">
  <ion-label>
    Secondary Color Item
  </ion-label>
</ion-item>

Detail Arrows

<ion-item detail>
  <ion-label>
    Standard Item with Detail Arrow
  </ion-label>
</ion-item>

<ion-item (click)="buttonClick()" detail>
  <ion-label>
    Button Item with Detail Arrow
  </ion-label>
</ion-item>

<ion-item detail="false" href="https://www.ionicframework.com">
  <ion-label>
    Anchor Item with no Detail Arrow
  </ion-label>
</ion-item>

List Items

<ion-list>
  <ion-item>
    <ion-label>
      Item
    </ion-label>
  </ion-item>

  <ion-item lines="none">
    <ion-label>
      No Lines Item
    </ion-label>
  </ion-item>

  <ion-item>
    <ion-label text-wrap>
    Multiline text that should wrap when it is too long
    to fit on one line in the item.
    </ion-label>
  </ion-item>

  <ion-item>
    <ion-label text-wrap>
      <ion-text color="primary">
        <h3>H3 Primary Title</h3>
      </ion-text>
      <p>Paragraph line 1</p>
      <ion-text color="secondary">
        <p>Paragraph line 2 secondary</p>
      </ion-text>
    </ion-label>
  </ion-item>

  <ion-item lines="full">
    <ion-label>
      Item with Full Lines
    </ion-label>
  </ion-item>

</ion-list>

Item Lines

<!-- Item Inset Lines -->
<ion-item lines="inset">
  <ion-label>Item Lines Inset</ion-label>
</ion-item>

<!-- Item Full Lines -->
<ion-item lines="full">
  <ion-label>Item Lines Full</ion-label>
</ion-item>

<!-- Item None Lines -->
<ion-item lines="none">
  <ion-label>Item Lines None</ion-label>
</ion-item>

<!-- List Full Lines -->
<ion-list lines="full">
  <ion-item>
    <ion-label>Full Lines Item 1</ion-label>
  </ion-item>

  <ion-item>
    <ion-label>Full Lines Item 2</ion-label>
  </ion-item>
</ion-list>

<!-- List Inset Lines -->
<ion-list lines="inset">
  <ion-item>
    <ion-label>Inset Lines Item 1</ion-label>
  </ion-item>

  <ion-item>
    <ion-label>Inset Lines Item 2</ion-label>
  </ion-item>
</ion-list>

<!-- List No Lines -->
<ion-list lines="none">
  <ion-item>
    <ion-label>No lines Item 1</ion-label>
  </ion-item>

  <ion-item>
    <ion-label>No lines Item 2</ion-label>
  </ion-item>

  <ion-item>
    <ion-label>No lines Item 3</ion-label>
  </ion-item>
</ion-list>

Media Items

<ion-item (click)="testClick()">
  <ion-avatar slot="start">
  </ion-avatar>
  <ion-label>
    Avatar Start, Button Item
  </ion-label>
</ion-item>

<ion-item href="#">
  <ion-label>
    Thumbnail End, Anchor Item
  </ion-label>
  <ion-thumbnail slot="end">
  </ion-thumbnail>
</ion-item>

<ion-item>
  <ion-thumbnail slot="start">
  </ion-thumbnail>
  <ion-label>
    <h2>H2 Title Text</h2>
    <p>Button on right</p>
  </ion-label>
  <ion-button fill="outline" slot="end">View</ion-button>
</ion-item>

<ion-item (click)="testClick()">
  <ion-thumbnail slot="start">
  </ion-thumbnail>
  <ion-label>
    <h3>H3 Title Text</h3>
    <p>Icon on right</p>
  </ion-label>
  <ion-icon name="close-circle" slot="end"></ion-icon>
</ion-item>

Buttons in Items

<ion-item>
  <ion-button slot="start">
    Start
  </ion-button>
  <ion-label>Button Start/End</ion-label>
  <ion-button slot="end">
    End
  </ion-button>
</ion-item>

<ion-item>
  <ion-button slot="start">
    Start Icon
    <ion-icon name="home" slot="end"></ion-icon>
  </ion-button>
  <ion-label>Buttons with Icons</ion-label>
  <ion-button slot="end">
    <ion-icon name="star" slot="end"></ion-icon>
    End Icon
  </ion-button>
</ion-item>

<ion-item>
  <ion-button slot="start">
    <ion-icon slot="icon-only" name="navigate"></ion-icon>
  </ion-button>
  <ion-label>Icon only Buttons</ion-label>
  <ion-button slot="end">
    <ion-icon slot="icon-only" name="star"></ion-icon>
  </ion-button>
</ion-item>

Icons in Items

<ion-item>
  <ion-label>
    Icon End
  </ion-label>
  <ion-icon name="information-circle" slot="end"></ion-icon>
</ion-item>

<ion-item>
  <ion-label>
    Large Icon End
  </ion-label>
  <ion-icon name="information-circle" size="large" slot="end"></ion-icon>
</ion-item>

<ion-item>
  <ion-label>
    Small Icon End
  </ion-label>
  <ion-icon name="information-circle" size="small" slot="end"></ion-icon>
</ion-item>

<ion-item>
  <ion-icon name="star" slot="start"></ion-icon>
  <ion-label>
    Icon Start
  </ion-label>
</ion-item>

<ion-item>
  <ion-label>
    Two Icons End
  </ion-label>
  <ion-icon name="checkmark-circle" slot="end"></ion-icon>
  <ion-icon name="shuffle" slot="end"></ion-icon>
</ion-item>

Item Inputs

<ion-item>
  <ion-label position="floating">Datetime</ion-label>
  <ion-datetime></ion-datetime>
</ion-item>

<ion-item>
  <ion-label position="floating">Select</ion-label>
  <ion-select>
    <ion-select-option value="">No Game Console</ion-select-option>
    <ion-select-option value="nes">NES</ion-select-option>
    <ion-select-option value="n64" selected>Nintendo64</ion-select-option>
    <ion-select-option value="ps">PlayStation</ion-select-option>
    <ion-select-option value="genesis">Sega Genesis</ion-select-option>
    <ion-select-option value="saturn">Sega Saturn</ion-select-option>
    <ion-select-option value="snes">SNES</ion-select-option>
  </ion-select>
</ion-item>

<ion-item>
  <ion-label>Toggle</ion-label>
  <ion-toggle slot="end"></ion-toggle>
</ion-item>

<ion-item>
  <ion-label position="floating">Floating Input</ion-label>
  <ion-input></ion-input>
</ion-item>

<ion-item>
  <ion-label>Input (placeholder)</ion-label>
  <ion-input placeholder="Placeholder"></ion-input>
</ion-item>

<ion-item>
  <ion-label>Checkbox</ion-label>
  <ion-checkbox slot="start"></ion-checkbox>
</ion-item>

<ion-item>
  <ion-label>Range</ion-label>
  <ion-range></ion-range>
</ion-item>

Basic Usage

<!-- Default Item -->
<ion-item>
  <ion-label>
    Item
  </ion-label>
</ion-item>

<!-- Item as a Button -->
<ion-item onclick="buttonClick()">
  <ion-label>
    Button Item
  </ion-label>
</ion-item>

<!-- Item as an Anchor -->
<ion-item href="https://www.ionicframework.com">
  <ion-label>
    Anchor Item
  </ion-label>
</ion-item>

<ion-item color="secondary">
  <ion-label>
    Secondary Color Item
  </ion-label>
</ion-item>

Detail Arrows

<ion-item detail>
  <ion-label>
    Standard Item with Detail Arrow
  </ion-label>
</ion-item>

<ion-item onclick="buttonClick()" detail>
  <ion-label>
    Button Item with Detail Arrow
  </ion-label>
</ion-item>

<ion-item detail="false" href="https://www.ionicframework.com">
  <ion-label>
    Anchor Item with no Detail Arrow
  </ion-label>
</ion-item>

List Items

<ion-list>
  <ion-item>
    <ion-label>
      Item
    </ion-label>
  </ion-item>

  <ion-item lines="none">
    <ion-label>
      No Lines Item
    </ion-label>
  </ion-item>

  <ion-item>
    <ion-label text-wrap>
    Multiline text that should wrap when it is too long
    to fit on one line in the item.
    </ion-label>
  </ion-item>

  <ion-item>
    <ion-label text-wrap>
      <ion-text color="primary">
        <h3>H3 Primary Title</h3>
      </ion-text>
      <p>Paragraph line 1</p>
      <ion-text color="secondary">
        <p>Paragraph line 2 secondary</p>
      </ion-text>
    </ion-label>
  </ion-item>

  <ion-item lines="full">
    <ion-label>
      Item with Full Lines
    </ion-label>
  </ion-item>

</ion-list>

Item Lines

<!-- Item Inset Lines -->
<ion-item lines="inset">
  <ion-label>Item Lines Inset</ion-label>
</ion-item>

<!-- Item Full Lines -->
<ion-item lines="full">
  <ion-label>Item Lines Full</ion-label>
</ion-item>

<!-- Item None Lines -->
<ion-item lines="none">
  <ion-label>Item Lines None</ion-label>
</ion-item>

<!-- List Full Lines -->
<ion-list lines="full">
  <ion-item>
    <ion-label>Full Lines Item 1</ion-label>
  </ion-item>

  <ion-item>
    <ion-label>Full Lines Item 2</ion-label>
  </ion-item>
</ion-list>

<!-- List Inset Lines -->
<ion-list lines="inset">
  <ion-item>
    <ion-label>Inset Lines Item 1</ion-label>
  </ion-item>

  <ion-item>
    <ion-label>Inset Lines Item 2</ion-label>
  </ion-item>
</ion-list>

<!-- List No Lines -->
<ion-list lines="none">
  <ion-item>
    <ion-label>No lines Item 1</ion-label>
  </ion-item>

  <ion-item>
    <ion-label>No lines Item 2</ion-label>
  </ion-item>

  <ion-item>
    <ion-label>No lines Item 3</ion-label>
  </ion-item>
</ion-list>

Media Items

<ion-item onclick="testClick()">
  <ion-avatar slot="start">
  </ion-avatar>
  <ion-label>
    Avatar Start, Button Item
  </ion-label>
</ion-item>

<ion-item href="#">
  <ion-label>
    Thumbnail End, Anchor Item
  </ion-label>
  <ion-thumbnail slot="end">
  </ion-thumbnail>
</ion-item>

<ion-item>
  <ion-thumbnail slot="start">
  </ion-thumbnail>
  <ion-label>
    <h2>H2 Title Text</h2>
    <p>Button on right</p>
  </ion-label>
  <ion-button fill="outline" slot="end">View</ion-button>
</ion-item>

<ion-item onclick="testClick()">
  <ion-thumbnail slot="start">
  </ion-thumbnail>
  <ion-label>
    <h3>H3 Title Text</h3>
    <p>Icon on right</p>
  </ion-label>
  <ion-icon name="close-circle" slot="end"></ion-icon>
</ion-item>

Buttons in Items

<ion-item>
  <ion-button slot="start">
    Start
  </ion-button>
  <ion-label>Button Start/End</ion-label>
  <ion-button slot="end">
    End
  </ion-button>
</ion-item>

<ion-item>
  <ion-button slot="start">
    Start Icon
    <ion-icon name="home" slot="end"></ion-icon>
  </ion-button>
  <ion-label>Buttons with Icons</ion-label>
  <ion-button slot="end">
    <ion-icon name="star" slot="end"></ion-icon>
    End Icon
  </ion-button>
</ion-item>

<ion-item>
  <ion-button slot="start">
    <ion-icon slot="icon-only" name="navigate"></ion-icon>
  </ion-button>
  <ion-label>Icon only Buttons</ion-label>
  <ion-button slot="end">
    <ion-icon slot="icon-only" name="star"></ion-icon>
  </ion-button>
</ion-item>

Icons in Items

<ion-item>
  <ion-label>
    Icon End
  </ion-label>
  <ion-icon name="information-circle" slot="end"></ion-icon>
</ion-item>

<ion-item>
  <ion-label>
    Large Icon End
  </ion-label>
  <ion-icon name="information-circle" size="large" slot="end"></ion-icon>
</ion-item>

<ion-item>
  <ion-label>
    Small Icon End
  </ion-label>
  <ion-icon name="information-circle" size="small" slot="end"></ion-icon>
</ion-item>

<ion-item>
  <ion-icon name="star" slot="start"></ion-icon>
  <ion-label>
    Icon Start
  </ion-label>
</ion-item>

<ion-item>
  <ion-label>
    Two Icons End
  </ion-label>
  <ion-icon name="checkmark-circle" slot="end"></ion-icon>
  <ion-icon name="shuffle" slot="end"></ion-icon>
</ion-item>

Item Inputs

<ion-item>
  <ion-label position="floating">Datetime</ion-label>
  <ion-datetime></ion-datetime>
</ion-item>

<ion-item>
  <ion-label position="floating">Select</ion-label>
  <ion-select>
    <ion-select-option value="">No Game Console</ion-select-option>
    <ion-select-option value="nes">NES</ion-select-option>
    <ion-select-option value="n64" selected>Nintendo64</ion-select-option>
    <ion-select-option value="ps">PlayStation</ion-select-option>
    <ion-select-option value="genesis">Sega Genesis</ion-select-option>
    <ion-select-option value="saturn">Sega Saturn</ion-select-option>
    <ion-select-option value="snes">SNES</ion-select-option>
  </ion-select>
</ion-item>

<ion-item>
  <ion-label>Toggle</ion-label>
  <ion-toggle slot="end"></ion-toggle>
</ion-item>

<ion-item>
  <ion-label position="floating">Floating Input</ion-label>
  <ion-input></ion-input>
</ion-item>

<ion-item>
  <ion-label>Input (placeholder)</ion-label>
  <ion-input placeholder="Placeholder"></ion-input>
</ion-item>

<ion-item>
  <ion-label>Checkbox</ion-label>
  <ion-checkbox slot="start"></ion-checkbox>
</ion-item>

<ion-item>
  <ion-label>Range</ion-label>
  <ion-range></ion-range>
</ion-item>

Properties

button

Description

If true, a button tag will be rendered and the item will be tappable.

Attribute button
Type boolean

color

Description

The color to use from your application's color palette. Default options are: "primary", "secondary", "tertiary", "success", "warning", "danger", "light", "medium", and "dark". For more information on colors, see theming.

Attribute color
Type string | undefined

detail

Description

If true, a detail arrow will appear on the item. Defaults to false unless the mode is ios and an href, onclick or button property is present.

Attribute detail
Type boolean | undefined

detailIcon

Description

The icon to use when detail is set to true.

Attribute detail-icon
Type string

disabled

Description

If true, the user cannot interact with the item.

Attribute disabled
Type boolean

href

Description

Contains a URL or a URL fragment that the hyperlink points to. If this property is set, an anchor tag will be rendered.

Attribute href
Type string | undefined

lines

Description

How the bottom border should be displayed on the item.

Attribute lines
Type "full" | "inset" | "none" | undefined

mode

Description

The mode determines which platform styles to use.

Attribute mode
Type "ios" | "md"

routerDirection

Description

When using a router, it specifies the transition direction when navigating to another page using href.

Attribute router-direction
Type "back" | "forward" | "root"

type

Description

The type of the button. Only used when an onclick or button property is present.

Attribute type
Type "button" | "reset" | "submit"

CSS Custom Properties

Name Description
--background Background of the item
--background-activated Background of the activated item
--border-color Color of the item border
--border-radius Radius of the item border
--border-style Style of the item border
--border-width Width of the item border
--box-shadow Box shadow of the item
--color Color of the item
--detail-icon-color Color of the item detail icon
--detail-icon-font-size Font size of the item detail icon
--detail-icon-opacity Opacity of the item detail icon
--highlight-color-focused The color of the highlight on the item when focused
--highlight-color-invalid The color of the highlight on the item when invalid
--highlight-color-valid The color of the highlight on the item when valid
--highlight-height The height of the highlight on the item
--inner-border-width Width of the item inner border
--inner-box-shadow Box shadow of the item inner
--inner-padding-bottom Bottom padding of the item inner
--inner-padding-end End padding of the item inner
--inner-padding-start Start padding of the item inner
--inner-padding-top Top padding of the item inner
--min-height Minimum height of the item
--padding-bottom Bottom padding of the item
--padding-end End padding of the item
--padding-start Start padding of the item
--padding-top Top padding of the item
--transition Transition of the item

Slots

Name Description
Content is placed between the named slots if provided without a slot.
"end" Content is placed to the right of the item text in LTR, and to the left in RTL.
"start" Content is placed to the left of the item text in LTR, and to the right in RTL.
